ZODIAC Photo Libraries
ZODIAC Photo Gallery #79

Click on thumbnail images for full-size picture. Choose additional photo galleries on left-hand menu.

ZODIAC XL - S-LSA Custom instrument panel with Dynon equipped EFIS (Electronic Flight Information System) and EMS (Engine Monitor System).
Zodiac XL Continental O-200 powered ZODIAC XL with a Dynon equipped EFIS (Electronic Flight Information System) and EMS (Engine Monitor System).
Zodiac German Zodiac XL
O-200 100-hp engine Continental O-200 engine installation in a Zodiac XL
cont1.jpg (53185 bytes) Continental O-200 engine installation in a Zodiac XL
Jabiru 3300 Tony Graziano's ZODIAC XL powered by the Jabiru 3300 (Buchanan, Tennessee).

"I attended the factory rudder workshop in October 2003 (highly recommended), and picked up the kit at the Zenith factory in January '04. First taxi test was on June 24, 2005.  Logged build hours: 792.

"The airplane has a full panel, including a Blue Mountain EFIS, Grand Rapids EIS, Trio Avionics autopilot, Garmin GPS-295, and more...

"Factory support from Zenith and Jabiru has been OUTSTANDING!  This is a FUN flying airplane!  Thanks for the great support and a superior product."

Tweety...
Full panel
Zodiac XL and 701 Two Zodiac XL trainers with one STOL CH 701
X-Plane Zodiac XL flight simulator screen shot.
instrument panel View of the instrument panel from the air (with lots of bugs on the windshield)
South African Zodiac South African Zodiac
South African Zodiac
Baggage After unpacking the Zodiac...
Photoshop demonstration Photoshop demonstration of climb performance
Zodiac tails at the Sentimental Journey fly-in at Lock Haven, Pennsylvania (June 2005).
Trying out the Zodiac XL at the Paris Airshow
Pictorial: Flying along the coastal bluffs (Kemble) in a Zodiac
  • Click here for more photos from Viktor of Switzerland
Zodiac Zodiac XL
Zodiac French Zodiac CH 601
Zodiac
Zodiac XL flanked by two STOL CH 701s at the Arlington NWEAA fly-in (July 2005)
Lycoming-powered ZODIAC XL


Previous Photo Gallery Next Photo Gallery


"The Zenith literature package is easily the most complete package I have received from any light aviation company, and I’ve seen many other good ones among the hundreds I have studied. Lots and lots of information is presented with some lovely graphics. The literature alone is impressive, but the volume of information will keep you reading for hours. You can get a good idea of what you're buying without ever leaving your chair."

EAA Experimenter magazine

  • Click here to order the ZODIAC Info Kit with an all-new DVD

Note: Many of these images show customer-built aircraft, some of which have been modified without the designer's specific approval. Modifications will affect the specifications and performance of the aircraft.
