Powerplant / Engine Installations: Page 1 of 2


Many of the following photos show custom engine installations, some of which have been modified without the designer's specific approval.  Alternative engine installations affect performance and specifications of the aircraft.
Click on thumbnail images for full-size picture.

Jabiru 3300 Engine Installation Jabiru 3300 engine installation in the ZODIAC XL.
Continental O-200 Engine Installation Continental O-200 engine installation in a Zodiac XL.
Custom CORVAIR Engine Installation Corvair installation.
Running up the Rotax 912S Running up the Rotax 912S for the first time
Rotax 912S Installation on a Zodiac XL Rotax 912S Installation on a Zodiac XL
Rotax 912S Installation on a Zodiac XL Rotax 912S Installation on a Zodiac XL
Rotax 912S Installation on a Zodiac XL Getting ready to bolt on the Rotax 912S engine: Engine bed mount plus accessories on the firewall.
Rotax Engine Installation Rotax 912 Installation, internal radiator mounting, IVO-prop in-flight adjustable propeller. This installation has a super-quiet muffler system (required by regs in Germany).
Rotax Engine Installation Rotax 912 installation in a ZODIAC.
100 hp Rotax 912 Rotax 912 installation in a ZODIAC.
Continental C-75 Installation Continental C-75 Installation (75 hp)
Continental C-75 Installation
Continental O-200 engine installation Running up the Continental engine...
Continental O-200 Installation Continental O-200 Installation (100 hp)
Continental O-200 Installation Another custom Continental O-200 installation.
turboprop A turbine installation: 90 hp Garrett turboshaft engine...
Click here
for more information on this unique installation.
Mercedes Benz Smart car turbo diesel custom aircraft engine installation A custom turbo-diesel engine installation (82-hp "Smart"-car engine) Mercedes Benz Smart car turbo diesel aircraft engine installation
Mercedes Benz Smart car turbo diesel custom aircraft engine installation A custom turbo diesel engine installation (82-hp "Smart"-car engine) on a Zodiac CH601
Smart diesel A custom turbo-diesel engine installation (82-hp "Smart"-car engine) on a Zenair CH 601
Yamaha Yamaha four stroke snowmobile engine installation on a Zodiac XL
Corvair Corvair Engine Installation
Jabiru 3300 Engine Installation Jabiru 3300 Engine Installation
Jabiru Jabiru 3300 Engine Installation
Jabiru 2200 installation in a Zodiac CH 601 Jabiru 2200 (80-hp, 4 cylinder) installation in a Zodiac CH 601
Jabiru 2200 Custom Installation Jabiru 2200 (80-hp) installation.
Jabiru 2200 Custom Installation Jabiru 2200 (80-hp) installation and custom fiberglass cowl.
  • Engine Installations: Page 1 of 2: Click here for page 2
  • Click here for details about engines for the ZODIAC
  • Click here for more Zodiac aircraft engine installation photos (photo directory).

"The Zenith literature package is easily the most complete package I have received from any light aviation company, and I’ve seen many other good ones among the hundreds I have studied. Lots and lots of information is presented with some lovely graphics. The literature alone is impressive, but the volume of information will keep you reading for hours. You can get a good idea of what you're buying without ever leaving your chair."

EAA Experimenter magazine


Note: Many of these images show customer-built aircraft, some of which have been modified without the designer's specific approval.  Alternate engine installations will affect performance and specifications of the aircraft.
