ZODIAC Photo Libraries
ZODIAC Photo Gallery #84


Click on thumbnail images for full-size picture. Choose additional photo galleries on left-hand menu.

Jabiru 3300 powered Zodiac XL Jabiru-powered Zodiac XL
Jim Pensinger's ZODIAC XL (Afton, Tennessee):

"N250JP first flew on September 4, 2005 with no surprises.  I attended the Zenith Rudder Workshop the week before Thanksgiving 2004 giving a total build time of a little over 9 months.   The engine is a Jabiru 3300 with a Sensenich wooden propeller.  The panel is IFR with a Dynon EFIS, Grand Rapids EIS and TruTrak autopilot.  Avionics include a Garmin 430, King KX125, King KT76 transponder and a Jim Weir kit audio panel.  Fuel capacity is 48 gallons giving range of 9 hours at 130 mph although I doubt that I will ever use its full capacity!
"Many thanks to Zenith for the great design, helpful staff and willingness to provide flying time while I was building.
"

plans-build Zodiac Larry McFarland's plans-build Zodiac (powered by a custom Subaru installation)
  • Click here to visit his excellent and very comprehensive website on scratch-building his aircraft.
ZODIAC XL S-LSA AMD Zodiac XL S-LSA test aircraft with a Continental O-200 powerplant and Dynon EFIS (Electronic Flight Information System) and EMS (Engine Monitor System).
S-LSA Zodiac Notice the boom on the left wing for testing and calibrating airspeed figures for LSA certification.
Zodiac Zodiac XL
ZODIAC XL on grass farm field...
S-LSA Zodiac 601XL manufactured and certified as an S-LSA by Czeck Aircraft Works on Oct. 3, 2005 in Lakeland, Florida.
ZODIAC taildragger ZODIAC taildragger
ZODIAC XL in Norway

This photo was listed on frappr.com, a cool online website that allows builders to graphically locate themselves on a map.

ZODIAC grass-field take-off
Two customized plans-build Zodiacs in Poland
Poland
Plans-built Zodiac CH 601 Plans-built Zodiac CH 601
Zodiac XL S-LSA Zodiac XL S-LSA
Zodiac CH 601
Zodiac XL Zodiac XL
Plans-build Zodiac airframe Plans-build Zodiac CH 601 airframe, waiting for the engine installation


Previous Photo Gallery Next Photo Gallery


"The Zenith literature package is easily the most complete package I have received from any light aviation company, and I’ve seen many other good ones among the hundreds I have studied. Lots and lots of information is presented with some lovely graphics. The literature alone is impressive, but the volume of information will keep you reading for hours. You can get a good idea of what you're buying without ever leaving your chair."

EAA Experimenter magazine

  • Click here to order the ZODIAC Info Kit with an all-new DVD

Note: Many of these images show customer-built aircraft, some of which have been modified without the designer's specific approval. Modifications will affect the specifications and performance of the aircraft.
