ZODIAC Photo Libraries
ZODIAC Photo Gallery #87


Click on thumbnail images for full-size picture. Choose additional photo galleries on left-hand menu.


ZODIAC XL

B.J. Ramsey's ZODIAC XL (Springfield, Illinois):

"After approximately 350 hours build time and much anticipation N549BJ test flew today (Jan 22, 2006).  It flew precisely as advertised by Zenith. It is the most comfortable and pilot and user friendly aircraft I have ever flown."



Basic panel with custom "golf ball" throttle and a fighter control stick.


Before... Twelve Months From Box to Chocks Before "Twelve Months From Box to Chocks"

Rick Morris of Markwood, Victoria, Australia sent us these before and after photos of his taildragger ZODIAC XL project...

After... Twelve Months From Box to Chocks

After

Corvair powered Zodiac XL

Corvair powered Zodiac XL

Zodiac CH601 in Spain

Taildragger Zodiac CH601 in Spain

Zodiac

Canadian Zodiac with a custom engine installation.

O-200 Continental

Mark Wood's Continental O-200 powered Zodiac CH 601 HD (Middlebury, Vermont):

"I’m having way too much fun to take it back to my garage to paint."

Midland, Ontario

Chris Heintz' prototype ZODIAC XL in Midland, Ontario, Canada after a snow storm.
(March 2006)

Zodiac XL

ZODIAC XL, custom instrument panel and seats.

Zodiac XL

Canadian ZODIAC XL

Zodiac CH 601

Zodiac CH 601 next to a Rans aircraft (in Germany)

Australian ZODIAC XL taildragger
Glen West

Zodiac XL

Glen West's Jabiru-powered Zodiac XL (Hurricane, Utah):

"After completing a STOL CH 801, which by the way flies perfectly, the new sport pilot rule and the experience and training received on the 801 helped with the desire to build the 601. My son Jesse and I drove back to Mexico and attended the rudder class and built the rudder in one day, pick up the CH 601 package and off we went back to Utah pulling a large U-haul trailer. That was in November of 2003, with no pressure to build and fly, because the 801 was taking care of that, we finished the 601 in December of 2005."

Jabiru-powered Zodiac XL

Jabiru-powered Zodiac XL

Zodiac CH 601 XL

zodiac 601

Zodiac

Zodiac wing baggage locker

Zodiac

Zodiac aircraft

Zodiac XL

Taxi testing a Zodiac XL

Taildragger Zodiac CH601


 Previous Photo Gallery

Next Photo Gallery







"The Zenith literature package is easily the most complete package I have received from any light aviation company, and I’ve seen many other good ones among the hundreds I have studied. Lots and lots of information is presented with some lovely graphics. The literature alone is impressive, but the volume of information will keep you reading for hours. You can get a good idea of what you're buying without ever leaving your chair."

EAA Experimenter magazine

  • Click here to order the ZODIAC Info Kit with an all-new DVD

Note: Many of these images show customer-built aircraft, some of which have been modified without the designer's specific approval. Modifications will affect the specifications and performance of the aircraft.
