Zodiac Kit Aircraft Builder Completions - Photo Gallery #9


Click on thumbnail images for full-size picture.

Taxiing on grass field Taxiing a taildragger Zodiac CH 601 on a grass field.
ZODIAC CH 601 HD.
Zodiac CH 601 ZODIAC CH 601 HDS
ZODIAC XL, powered by a six cylinder Jabiru 3300 engine. ZODIAC XL, powered by a six cylinder Jabiru 3300 engine.
ZODIAC CH 601 in New Zealand.
German ZODIAC CH 601.
British ZODIAC CH 601 HD with twin rotary engine with full electronic fuel injection system (105 BHP).
British ZODIAC CH 601 HD with twin rotary engine with full electronic fuel injection system (105 BHP).
British ZODIAC CH 601 HD with twin rotary engine with full electronic fuel injection system (105 BHP).
A plans-built ZODIAC CH 601 HD with 75-hp Continental engine.
Two ZODIAC CH 601 UL with Canopy Cover for outdoor storage (Italy).
ZODIAC CH 601 HD with VW engine installation
Super ZODIAC CH 601 HDS, TD gear.
Zodiac XL ZODIAC XL in a hangar
ZODIAC CH 601 HD, powered by EA-82 Subaru.
Built from "scratch" in three years - notice the custom canopy.
Custom ZODIAC canopy hinges forward.
Flying cross country Zodiac CH 601 - Flying cross country.
Zodiac CH601 Zodiac CH 601 on grass field
Hand towing the Zodiac (on grass field)
Zodiac CH 601 ...ready to go!
napping under the wing ...resting under the wing...
Another custom canopy like the new ZODIAC CH 601 XL.
This ZODIAC is an HD model with a Lycoming O-235 engine.
Here's another customer-modified canopy system on a ZODIAC - this unique one swings up from the back.
The canopy is a non-structural part of the airframe, and can thus be easily customized by the builder (a time consuming process).
ZODIAC CH 601 UL


Previous Photo Gallery Next Photo Gallery


Note: Many of these images show customer-built aircraft, some of which have been modified without the designer's specific approval. Modifications will affect the specifications and performance of the aircraft.
