PHOTO LIBRARY
DETAIL and MISCELLANEOUS VIEWS OF THE STOL CH 701

Click on thumbnail images for full-size picture:
Many of these images show customer-built aircraft, some of which have been modified without the designer's specific approval. Modifications will affect the specifications and performance of the aircraft.

Zenair CH701 cabin - designed for easy access A nice view of the cabin - the large doors allow for easy cabin access.
  • Click here for cabin dimensions and details (old style door)
Custom leather seats Custom leather seats
STOL CH 701 with the new bubble doors STOL CH 701 with the new bubble doors option.
swing-up door Open door...
  • Click here for photos of custom instrument panels
A nice view of the cabin - the large doors allow for easy cabin access Custom seats
Full window / door A nice view of the cabin... notice the full Lexan door/window on this STOL CH 701.
STOL CH 701 loaded in a container Shipping an assembled STOL CH 701 overseas in a standard 20-foot container.
STOL CH 701
Soft leather interior Custom leather seating.
Custom instrument panel Custom instrument panel photos
Landing Light Custom landing light on the STOL CH 701.  Notice the clear bubble doors.
STOL CH 701 custom seats STOL CH 701 custom seats.
custom interior Nice custom panel / interior
load test with sand bags: Zenair 701 wing Testing the STOL CH 701 wing loads.
BRS Recovery chute installation A custom Ballistic Recovery System (BRS) emergency chute installation in a STOL CH 701.
custom ballistic recovery parachute installation Another custom ballistic recovery parachute installation in the STOL CH 701, mounted in the rear baggage area.
Baggage door in fuselage Custom door is rear fuselage to access luggage in the rear baggage area of the STOL CH 701 cabin.
strobe light A wing tip strobe light.
belly cargo pod A custom fiberglass belly pod mounted under a STOL CH 701 for added cargo carrying capability.
Ghana flight training Flight training in the STOL CH 701
(Ghana, Africa).
STOL CH 701 instrument panel & cabin

Scratch-building a STOL CH 701 in the backyard.

Fuselage assembly Fuselage Assembly
Kit pick up Picking up the complete STOL CH 701 airframe kit at the Zenith factory, using a full-size pickup truck with an extension box to accommodate longer kit parts.
windshield canopy cover Windshield / canopy cover for the STOL CH 701 for outdoor storage / tie-down of the aircraft.
Custom arm rest in the STOL CH 701 A custom armrest between the seat of the STOL CH 701
Dual control sticks A custom dual control stick modification on a STOL CH 701
czaw-para5.jpg (52300 bytes) Auxiliary tank in right seat for agricultural spraying.
Easy-access doors
Comfortable side-by-side seating.
wings removed STOL CH 701 with the wings removed (lying behind on ground).

Related Info:


Note: Many of these images show customer-built aircraft, some of which have been modified without the designer's specific approval. Modifications will affect the specifications and performance of the aircraft.
