PHOTO LIBRARY
STOL CH 701 Photo Gallery 61

Click on the image for full-size view. Select other photo galleries from the menu list on the left.

701.jpg (69275 bytes) Zenith's factory demonstrator STOL CH 701 with the new domed bubble doors for a wider cabin and better visibility.
"This is my Zenith CH 701, a first time project of this kind, which took me 2 years to finish. It uses a Rotax 912 UL engine and flies beautifully. This plane was easy to transition from my Kolb Firestar ultralight. Hats off to Chris Heintz!"
Continental C-85 powered STOL CH 701 "on the farm..."
schwaller-1.jpg (58393 bytes) "My plans-built STOL CH 701 is finished after 1,617 hours of enjoyable work. Engine is a 1915 VW with a Valley Engineering reduction drive turning a 72 in. 3 blade ground-adjustable Ivo prop. Static thrust is 362 Ibs. at 3700 rpm. Thanks to Zenith Aircraft, they were very helpful all through this project. I am 74 years old and hope to fly this bird for a few more years."
Custom wheels Large 26-inch custom tires increase the off-airport capability of the STOL CH 701
6.jpg (21941 bytes) This is a French STOL CH 701, with a familiar paint scheme.
Zenair CH701 STOL Another STOL CH 701 with the now familiar paint scheme
STOL CH 701 landing

Landing the STOL CH 701 on a grass field.

CH701 STOL Flying the STOL CH 701 (Australia)
Finishing a STOL CH 701 (Australia)
Top View of the STOL CH 701
STOL CH 701 in South Africa
South Africa
STOL CH 701 STOL CH 701 with the Rotax 914 turbo
  STOL CH 701 - off airport mountain flying
701cfd.jpg (48178 bytes) STOL CH 701 with a custom Jabiru 3300 engine installation

 ... Previous Photo Gallery

 ... Next Photo Gallery



"The Zenith literature package is easily the most complete package I have received from any light aviation company, and I’ve seen many other good ones among the hundreds I have studied. Lots and lots of information is presented with some lovely graphics. The literature alone is impressive, but the volume of information will keep you reading for hours. You can get a good idea of what you're buying without ever leaving your chair."

EAA Experimenter magazine


Note: Many of these images show customer-built aircraft, some of which have been modified without the designer's specific approval. Modifications will affect the specifications and performance of the aircraft.
